All Material Handling 1.5 Ton 20′ Lever Hoist with Black Chain
$124.00
976 in stock
All Material Handling 1.5 Ton 20′ Lever Hoist with Black Chain
The All Material Handling LC015-20 lever chain hoist has easy one hand operation and set up. It allows for operation in any orientation. Light weight and durable formed steel enclosure.
Easy One Hand Operation and Setup – When the selector is in neutral and no load is present then free chain mode is entered. The chain can be pulled through the hoist by a pull handle for easy set up and load attachment before engaging the selector for pulling. The pull handle also acts as a chain stop. Short ratchet strokes of a non-slip rubber grip lever and 360 degree rotation requires minimal space for operation. The pull force to operate may be 20 to 30% less than others.
Operation in any orientation is assured by a fully enclosed horseshoe shape chain guard keeping the load chain in contact with the lift wheel.
Light weight and durable formed steel enclosure protects from contamination and can be quickly disassembled for fast and easy maintenance. Powder coating and plated finishes on exposed components are used for resistance to corrosion.
Internal parts are heat treated for strength and reliability with fully enclosed gearing to protect from contamination. All gears and shafts run on caged roller bearings including the lift wheel which is machined for smooth operation and long life.
Acme Tools Brand Name
ALL MATERIAL HANDLING
Acme Tools Category
hardware>lifting
Acme Tools Part Number
LC015-20B
Assembled Weight (lbs)
16.8
California Proposition 65 Warning Required
Yes
Country of Origin
China
globalTradeItemNumber (GTIN)
00412001000635
Package Contents
Lever Hoist
Package Depth
5.6
Package Height
20.2
Package Weight
16.8
UPC
412001000635
Weight Capacity (lbs)
3300
